textile waste/cotton waste recycling machine from China manufacturer

textile waste/cotton waste recycling machine

Price:	1.0~3.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Shandong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: gm-400-6

Production Capacity: 100

Delivery Date: within 45 days

fabric cotton waste recycling machine: textile waste recycling mac...

fabric shredder: cloth waste recycling machi...

Means of Transport: Ocean,Land

Packing: nude or wooden

Brand Name: jk

hard waste opening machine: cotton waste recycling mach...

gm-400-4 fabric cotton waste/textile waste recycling machine
high capacity
good function
new technology

GM-400-6 textile waste recycling machine

Useage:

Our textile waste recycling machine recycled kinds of textile waste (knitting hosiery fabric rags , hard waste thread , polyester ,cloth waste leftover of garment ) get the fiber from these waste enable use for rotor spinning and any other purpose ,make a good use of waste material will save cost , the fiber will be instead of raw cotton .make bebefit .

technical data of textile waste recycling machine

AA. 400-6 recycling machine
Main technical Parameter:
01. Nos. of Roller / Chamber : six cylinders /chambers
02. Nos of Roll dia : 400mm
03. Front roll dia : 400mm
04. Back Roll dia : 400mm
05. Dust Basket Dia : 530mm
06. Taker in Wire

1) first cylinder 4.5 /tpi

2) second cylinder 6 /tpi

3) third cylinder 7/tpi

4) forth 7.5tpi

07. Outside Dimension : 7200*1720*1160 mm (l*w*h)
08. Nos. of Motor & Capacity :

motor: first 11kw one set ; others 7.5kw three sets

capicaty : 150-200kgs /hour

09. Distance of Roll and Feed Plate: 300mm
10. Distance of feed roll and Feed Plate: 50mm

BB. Opening Machine mqk-1060 opening machine
01. Output :150-200kgs /hour
02. Roll Diameter : 600mm steel cylinder
03. Rotation speed : 1350rpm
04. Dust basket :    630mm
06. Fan Machine : 1.5kw one set
07. Chain : four pieces
08. Power : 18.5kw
09. Taker in wire : 3.5-4.5tpi
10. Dimension : 2600*1450*1550 mm about

CC. Cutting Machine qd-350 cutting machine
Technical parameter
01. Out put : 1000-1500kgs/hour
02. The Blade Roller Dia : 320mm
03. Speed of the Roller :   230rpm
04. Nos. of Motor Blade Roller : Y132S-8,5.5KW   1 set

feeding and discharging Y 90L-4,1.5KW 1Set
05. Chief Bearing : 6216E 4 (blade roller)
06. Conveyor Belt :

(1) 380×2100×4 1(feeding part)

380×2750×4 1(discharging)

07. over all : 2500*960*1500
